| LC11D-06A10 | |
| length | 31.1mm |
| Rated voltage (Vm) DC | 2.7 |
| A/phase | 1 |
| R/phase Rm (ohm) | 2.7 |
| Inductance/phase（MH@1000Hz） | 2.4 |
| Minimum holding torque（N-cm） | 6 |
| Step Angle (degree) | 1.8 |
| Step accuracy (non-cumulative)% | ±5 |
| LC11D-12A10 | |
| length | 44.4mm |
| Rated voltage (Vm) DC | 3.2 |
| A/phase | 1 |
| R/phase Rm (ohm) | 3.2 |
| Inductance/phase（MH@1000Hz） | 4 |
| Minimum holding torque（N-cm） | 12 |
| Step Angle (degree) | 1.8 |
| Step accuracy (non-cumulative)% | ±5 |
