input voltage | 24-36 VDC |
sustained current | 15 A |
| Analog speed reference | 0 ~ 5 V |
work environment | 0 ~ +45 C |
| storage condition | -20 ~ +85 C |
operating humidity | < 85RH |
structure | Case |
type of cooling | IC411 |
| Speed and current loop |
| 20KHz PWM |
| DIP set speed range |
| On/off, forward/backward control |
| Electric brake |
| Stall protection |
| Double overload |
| Overvoltage, low voltage, overcurrent, overtemperature, or Hall sensor error warning. |
| V+ | Positive power |
| GND | Negative power |
| MA | Motor A phase |
| MB | Motor B phase |
| MC | Motor C phase |
| GND | Hall sensor power supply positive |
| HA | Hall sensor phase A |
| HB | Hall sensor phase B |
| HC | Hall sensor phase C |
| +6.25V | Hall sensor power supply negative |
| GND | Negative control power |
| F/R | Forward and backward |
| EN | make it possible |
| BK | brake |
| SV | Speed reference |
| PG | speed feedback |
| ALARM | siren |
| +6.25V | Control power positive |
